EFV-8 Club Forum / General Ford Discussion / Dash light switch

Reply to Discussion | New Discussion

<< previous || next >>

Posted By

Discussion Topic: Dash light switch

TNation

02-01-2016 @ 5:32 PM

reply profile send p.m.

Member
Posts: 22
Joined: Dec 2010

I'm looking for a sourch for a new dash light switch for my '36. It is the pull-push on-off switch for the instrument lights. Any help will be appreciated.

40 Coupe

02-02-2016 @ 6:59 AM

reply profile send p.m.

Senior
Posts: 1801
Joined: Oct 2009

They are not reproduced. You can use a 35 but the switch will work backward. The 36, 37 and maybe 38?? are nearly identical except for the knob, reproduction knobs are available. MANY original switches do not operate properly. If this is the case with your existing switch you can try to wedge a small piece of rigid plastic between the two electrical terminals. Try to wedge them so they do not angle toward each other and are straight, do not use excessive force. This often will correct the problem.

TNation

02-03-2016 @ 4:32 PM

reply profile send p.m.

Member
Posts: 22
Joined: Dec 2010

Thanks. I will give that a try.

mrtexas

02-03-2016 @ 5:56 PM

reply profile send p.m.

Member
Posts: 68
Joined: Dec 2011

I got mine on ebay, americas swap meet.

This message was edited by mrtexas on 2-3-16 @ 5:57 PM

fordv8j

02-04-2016 @ 3:07 PM

reply profile send p.m.

New Member
Posts: 194
Joined: Jan 2015

1938 dash light switch is a toggle switch

TNation

02-07-2016 @ 5:35 PM

reply profile send p.m.

Member
Posts: 22
Joined: Dec 2010

Thanks to all.

twostickmutt

02-12-2016 @ 12:58 PM

reply profile send p.m.

Member
Posts: 42
Joined: Feb 2016

did the 39's also have the toggle for dash lights ? mine has the wire for them but was just cut off. i was just going to wire them into the head lights. they work when i put power to them.

40 Coupe

02-13-2016 @ 7:19 AM

reply profile send p.m.

Senior
Posts: 1801
Joined: Oct 2009

First off I do not believe 38 passenger car had a toggle switch. I believe 34 was the last year for the toggle. 35-38 have similar push-pull switches. 39,40 and later used similar dash light rheostats so the lights could be dimed. The knob on the rheostat is plastic and matches the other knob colors on the interior. NOS are hard to come by but there are reproductions. Check Dennis Carpenter or Mac's or other suppliers.

40cpe

02-13-2016 @ 7:34 AM

reply profile send p.m.

Member
Posts: 488
Joined: Jan 2010

My '38 has a toggle switch under the dash left of the steering column. It is connected with the bullet connectors in the factory harness making me believe it is original. I see no other place in the face of the dash where a push/pull switch would be.
