EFV-8 Club Forum / General Mercury Discussion / Grille for a 47 Mercury 4dr sedan

   Reply to this DiscussionReply to Discussion | Start new discussionNew Discussion << previous || next >>
Posted By Discussion Topic: Grille for a 47 Mercury 4dr sedan -- page: 1 2

Printer-friendly Version  send this discussion to a friend  new posts last

deric47merc
11-07-2009 @ 4:17 PM
Member
Posts: 17
Joined: Nov 2009

Hey all,
This is my first post here! I have recently purchased a 1947 4 door sedan and need some help with a few things. the grille that is on there right now is cracked on the top shroud piece. i found that piece at a local shop where i am from (azusa, ca.) to come home and find out its a little different. oops! the difference is that the one i purchased has holes down the side of it to put some chrome or stainless little lines on it. there is 3 for each side. my current grille does not have that. after doing some research there seems to be two different grilles that one could purchase... with the 3 lines on the sides or not. also i noticed that some grilles seem to have the mercury logo above the top two different ways.. can someone with more knowledge then me explain this to me.. how do i know what grille to put on my car?

Thanks in advance.. Deric

trjford8
11-07-2009 @ 4:56 PM
Senior
Posts: 3410
Joined: Oct 2009

Deric, in looking at photos in The V-8 Album, put out by the V-8 Club, there is s difference in the grilles between 46 and 48 Mercs. The 46 was a painted grille surround and had the holes for the short chrome strips down the sides. The 47-48 grille had a chrome grille surround and no strips down the sides. It is also possible that Merc was like Ford after the war. Many 46 parts came on the early 47 cars. It's possible that the grill you purchased was an early 47. You definitely want to replace your grille with one that is like the one on your car.
Hopefully TomO who is the resident Merc guy on the forum will weigh in on this discussion.


This message was edited by trjford8 on 11-7-09 @ 4:59 PM

TomO
11-08-2009 @ 8:49 AM
Senior
Posts: 5885
Joined: Oct 2009

The part that you purchased appears to be P/N 59A-8350. It would have been painted body color with 3 chrome strips on each side.

The part on your car would be P/N 6M-8350 and would be chrome plated.

The painted part was use on 1946 cars and early 1947 cars, the chrome plated was used on late 1947 cars and 1948 cars. I don't know the change over date, but it was early in 1947.

The Mercury name plate had a red background on the 46 and early 47 cars. The late 47 and 48 cars had a black background.

I hope that this helps you.

Tom

deric47merc
11-09-2009 @ 9:43 AM
Member
Posts: 17
Joined: Nov 2009

thanks.. this is very helpful. i guess ill just have to fill the holes on the part that i just purchased. i have another (dumb) question. so, on the dash i have a L knob (lights) and a T knob. the T knob pulls all the way out so i will need to fix that..what is that for? Also, my heater says ford on it, is that right in a Merc?
Thanks

fsacht
11-09-2009 @ 12:53 PM
Member
Posts: 63
Joined: Oct 2009

T is for throttle. If pulls all the way out means a few inches then stops, that is what it should do.
The engine end connects to the left side of the carburator thottle shaft with a ball connection like that of the choke. One of my Mercury's has an 8BA engine in it and that carb has no throttle attachment. If your distributor is at the right front of the engine that's what you have. If the distributor is on the front face of the block that's what you should have 46 - 48

TomO
11-10-2009 @ 8:04 AM
Senior
Posts: 5885
Joined: Oct 2009

I don't remember a Mercury name on the heater in 1947. There were 3 heaters available in 1947, one with 3 doors on the front, a fresh air heater and a third heater with one door in the front and 1 small door on each side.

Which heater do you have?

Tom

deric47merc
11-10-2009 @ 9:28 AM
Member
Posts: 17
Joined: Nov 2009

Here is a pic...

deric47merc
11-10-2009 @ 9:30 AM
Member
Posts: 17
Joined: Nov 2009

another pic...

TomO
11-11-2009 @ 7:45 AM
Senior
Posts: 5885
Joined: Oct 2009

I don't recognize your heater. It might be from a truck or commercial vehicle manufactured after 1947. I think that the block letters came into use in the 50's.

If you intend to put your car on the concourse for judging, I would get the 41-48 book from the V-8 Club and use it as a guide for a correct restoration.



Tom

This message was edited by TomO on 11-11-09 @ 7:47 AM

deric47merc
11-11-2009 @ 8:46 AM
Member
Posts: 17
Joined: Nov 2009

Thanks for the info... the description of the book says
"186-page guideline for the 1941-1948 Ford Car" . Does it also cover mercury too?
