EFV-8 Club Forum / Light Commercial Truck Discussion / Oil filter location for a 1940 V8 95.

   Reply to this DiscussionReply to Discussion | Start new discussionNew Discussion << previous || next >>
Posted By Discussion Topic: Oil filter location for a 1940 V8 95.

Printer-friendly Version  send this discussion to a friend  new posts last

Awhite4610
09-09-2018 @ 5:44 AM
Member
Posts: 2
Joined: Sep 2018

I have a 1940 dump truck with a V8 95. Truck runs great . My question is did they have oil filters on commercial trucks and if so where should it be located.
Thanks

trjford8
09-09-2018 @ 7:19 AM
Senior
Posts: 4203
Joined: Oct 2009

Oil filters were optional. They were a canister type with a bracket that bolted to two or three head studs.

Awhite4610
09-09-2018 @ 12:36 PM
Member
Posts: 2
Joined: Sep 2018

thank you

wmsteed
10-05-2018 @ 7:25 AM
Senior
Posts: 606
Joined: Oct 2009

The oil filter, a Fram C-4 as I recall, was generally bolted to the left head, near the firewall..
I have attached a pix of a '49 trk engine with a oil fiter.

Bill
36 5 win delx cpe

MGG
10-05-2018 @ 4:16 PM
Member
Posts: 85
Joined: Jul 2014

The picture by wmsteed is for the 8BA model engine. It has designated holes in the left head for the filter canister bracket. On my 40 truck like yours, the filter canister is bolted to the head bolts almost centered on the left side head. The mounting holes in the 40 filter canister base are not the same as for the 8BA. My 47 truck which has an 8BA in it has the filter as pictured.

TomO
10-06-2018 @ 7:56 AM
Senior
Posts: 7244
Joined: Oct 2009

Here are the installation instructions for the late 1940 oil filter.

Tom
