EFV-8 Club Forum / 1940 Ford Discussion / fuzy strip on garnish molding

Reply to Discussion | New Discussion

<< previous || next >>

Posted By

Discussion Topic: fuzy strip on garnish molding

donnicoli

08-02-2015 @ 8:35 AM

reply profile send p.m.

Member
Posts: 56
Joined: Mar 2010

Do you actually use the staples to mount the fuzzy strip on the garnish molding? Is there a trick to doing this?
Do you bend the fuzzy strip to fit in the offset in the garnish where the window division bar goes? (photo attached)

kubes40

08-02-2015 @ 11:44 AM

reply profile send p.m.

Senior
Posts: 3368
Joined: Oct 2009

I just finished a set of these last week. Yes, bend the slight offset so the strips fit against the molding. I do not use staples. Rather, I use wire.
Push the wire through two holes, twist it "tight" and cut off the excess. The wire buries itself nicely within the "fuzz" and is easy to install.
You will need to form the repop strips to match the contour of your molding(s).
Mike "Kube" Kubarth

donnicoli

08-02-2015 @ 11:55 AM

reply profile send p.m.

Member
Posts: 56
Joined: Mar 2010

Thanks,Mike

donnicoli

08-02-2015 @ 7:27 PM

reply profile send p.m.

Member
Posts: 56
Joined: Mar 2010

Mike, is there some reason you can't drill holes and use the same clips like on the door?

kubes40

08-03-2015 @ 4:48 AM

reply profile send p.m.

Senior
Posts: 3368
Joined: Oct 2009

I use new clips to install the "fuzzy" to the door. Wire to install the "fuzzy" to the moldings.
Clips on the moldings would most likely interfere with the glass and ultimately scratch it.

kenburke

08-18-2015 @ 4:37 PM

reply profile send p.m.

New Member
Posts: 141
Joined: Oct 2009

Hi Mike, On the wire? What gauge is recommended? Thanks, KeB

kubes40

08-20-2015 @ 6:32 AM

reply profile send p.m.

Senior
Posts: 3368
Joined: Oct 2009

Hey Ken,
I use wire that is a nominal .040" in diameter. I prefer galvanized as it won't corrode. Stainless is too brittle.
This diameter allows an easy installation and it buries itself well in to the "fuzzy" so as not to be seen.
Mike

fortyford

11-03-2015 @ 5:12 PM

reply profile send p.m.

Member
Posts: 206
Joined: Nov 2009

I just got a window anti-rattler kit from Carpenters.I noticed the garnish strip has no holes for mounting.Do have to mark for the holes and how do you force the staples through?Do I have to pull the vent assembly out to install the new window channel for top of door?
